Showtec Phantom 25 Led Spot User Manual

The Phantom 25LED Spot MKII is the succesor of the phantom 25LED Spot. The MKII is improved with better components and a more efficient LED source. This results in 20% more light output. It is fully compatible with the MKI version and has the same colors and gobos with shake effect. The eight automatic and eight sound-to-light programs with master / slave function will ensure a quick and easy setup. It has a 6 and a 11 channel DMX personality. The weight is only 4,3 Kg and it has a single clamp bracket which makes it easy to handle and position in truss systems. Optional flightcase are available.

. Showtec Phantom 25 LED Spot with IEC powercable 0,9m. 1 bracket for truss mounting. Safety eye. User manual LED Expected Lifespan LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration of this decline.
The Phantom 25LED Spot MKII is the succesor of the phantom 25LED Spot. The MKII is improved with better components and a more efficient LED source. This results in 20% more light output. It is fully compatible with the MKI version and has the same colors and gobos with shake effect.

The Phantom 65 Spot is a very compact multifunctional moving light with a 65W white LED light source. It's the ultimate successor of the Spot 50 and comes with a complete package of features. It has 1 colour wheel, 1 rotating gobo wheel, prism and great optics with adjustable manual focus.

Specifications

Output
Beam Angle: 13°
Light Source: 1 x 25W White LED
Electrical
Input Voltage: 100-240 VAC
Power consumption: 65W max. at full output
LED Drive current: 1.45A
Control
On-Board: Display for auto and Sound control
Control Protocol: DMX512
Control Personality: Advanced 11ch /Basic 6ch
Optical system
Dimmer: 0-100%
Strobe: 0-20Hz
Focus: Manual focus
Movement
Pan: 540°
Tilt: 270°
Pan/Tilt resolution: 16 bit
Special: Pan / Tilt movement blackout
User-selectable Pan & Tilt ranges, 540°/360°/180°
Reverse Pan / Tilt movement
Gobos & Colors
Gobo: 9 metal gobos
Gobo functions: Gobo-flow effect, Gobo shake, Gobo-flow effect, Gobo shake
Gobo inner diameter: 15mm
Colors: 9 dichroic-filters + white
Color functions: Split colors, Rainbow-flow effect
Physical
Housing: Metal & Flame-retardant plastic
Color: Black
Fixture Connection: XLR Data in/out, IEC Power in
Dimensions (WxDxH): 205 x 210 x 310 mm
Weight: 5 kg
Certification and Safety
Certification: CE
Max. ambient Temp.: 40°C

Brand: Showtec
Product Code: 40204
Availability: 4 - 5 Days

£389.00
Ex Tax: £324.17

Showtec phantom 25 led spot user manual free

0 reviews / Write a review

The Phantom 50 MKII LED Spot is the bigger brother of the 25 LED Spot and has a 50W white LED light source. Besides the stronger output the 50 LED spot also has some extra functionality's like rotating gobo´s and a 3-facet prism. The 50 LED spot has 7 gobo´s with shake effect and the 9 dichros are the same as the 25 LED Spot. This makes them easy to combine. The 50 LED Spot can also be used as a master for the 25 LED spot in a master/slave setup. It has 2 personalities, an advanced 13-channel and a basic 8-channel setting. The weight is 5,6 Kg and it has only one clamp bracket which makes it easy to handle and position in truss systems. This little moving head will surprise you with its complete functionality and strong light output.

Specifications
Output
Lux @ 1m: 20.900
Beam Angle: 17°
Light Source: 1 x 50W White LED

Electrical
Input Voltage: 100-240 VAC
Power consumption: 93W max. at full output
LED Drive Current: 2A

Control
On-Board: LCD full color display
Control Protocol: DMX512
Control Personality: Advanced 13ch /Basic 8ch

Optical system
Dimmer: 0-100%
Strobe: 0-20Hz
Focus: Manual focus
Prism: 3-facet prism

Movement
Pan: 540°
Tilt: 270°
Pan/Tilt resolution: 16 bit
Special: Pan / Tilt movement blackout
User-selectable Pan & Tilt ranges, 540°/360°/180°
Reverse Pan / Tilt movement

Gobos & Colors
Gobo: 2 glass + 5 metal gobos (replaceable)
Gobo functions: Gobo-flow effect,Gobo shake
Rotation: Bi-directional
Gobo inner diameter: 20mm
Gobo outer diameter: 24mm
Colors: 8 dichroic-filters + white
Color functions: Split colors, Rainbow-flow effect
