The Hikvision DS-7604NI-K1/4P is the latest POE Channel Plug and Play NVR available, this new generation recorder has multiple advanced technologies, such as audio and video decoding technology, embedded system technology, storage technology, network technology and intelligent technology. It can both work alone as a recorder and/or interface with other ONVIF compatible devices to form a comprehensive surveillance system.
The Hikvision DS-7604NI-K1/4P (4 Channel) Network Video Recorders are our ‘go to’ solution where a rock solid minimal camera solution is required.
- Supports third-party ONVIF network cameras
- Up to 12 Megapixels resolution recording
- VGA, HMDI at up to 4K (3840×2160) resolution output
- 4 POE network camera support
- 40MB incoming bandwidth
- Supports up to 6TB HDD (3TB HDD included)
- Plug & Play with 4 independent PoE network interfaces
- Support H.265/H.264/MPEG4 video formats
- Software/Firmware upgradable
- 3-year manufacturers warranty
- Genuine Australian Stock
- Mobile Monitoring via Hik-Connect or iVMS-4500
DS-7604NI-K1-4P Datasheet
DS-7604NI-K1/4P User Manual Hikvision Website
Android Hik-Connect
Apple iOS Hik-Connect
PC & Mac IVMS-4200
Description
Ds 7604ni E1 Firmware
Ds 7604ni K1 4p B
Share the post 'DS-7604NI-E1/4P'
Ds 7604ni E1 4p Manual
| Model | DS-7604NI-E1/4P |
|---|---|
| IP video input: | 4-ch |
| Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Incoming bandwidth: | 40Mbps |
| Outgoing bandwidth: | 80Mbps |
| Remote connection: | 128 |
| HDMI/VGA output: | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Recording Resolution: | 6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate: | Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) |
| Audio Output: | 1-ch, RCA (Linear, 1kΩ) |
| Synchronous Playback: | 4-ch |
| Live view / Playback: | 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability: | 4-ch@1080P |
| SATA: | 1 SATA interface for 1 HDD |
| Capacity: | Up to 4TB for each disk |
| Network Interface: | 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
| USB Interface: | 1 × USB 2.0 and 1 × USB 3.0 |
| Alarm In: | 4-ch(optional) |
| Alarm Out: | 1-ch(optional) |
| Interface: | 4 independent 100 Mbps PoE network interfaces |
| Max. Power: | 50W |
| Supported Standard: | AF and AT |
| Power Supply: | 48V DC |
| Consumption(without hard disk and POE): | ≤ 10W |
| Working Temperature: | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity: | 10 % ~ 90 % |
| Chassis: | 1U chassis |
| Dimensions: | 315 × 230 × 45mm (12.4 ×9.1 × 1.8 inch) |
| Weight(without HDD): | ≤ 1 Kg (2.2 lb) |
